FUJI Fuji XP143 Pick and Place Machine

Max PCB: 508mm x 457mm
Component Capacity:Up To 100 types feeder
weight: 1.800 kg
Dimension: 1500x1300 (2143)x1409 mm

FUJI Fuji XP143 Pick and Place Machine


FUJI Fuji XP143 Pick and Place Machine

High speed placement at 0.165 sec / comp ( 21,800 cph)

On the fly vision

Fuji’s proprietary Multi-step (MS) vision processing Algorithm

Auto calibration

PCB Dimensions:

Max: 508mm x 457mm Min: 80mm x 50mm

Thickness: 0.5mm x 4.0mm

Component Capacity:

Up To 100 types (using 8 mm tape feeders.)

PCB loading Time: 4.2 sec.

Placing accuracy

Chips: ±0.05mm(3 Sigma),±0.1mm(6 Sigma)

QFPs: ±0.03mm(3 Sigma),±0.06mm(6 Sigma)

Applicable Components:

0603 (0201) to 20 x 20 mm, Max height 6.0 mm

Power*:3-phase 4 kVA 208-480VAC

Air Supply 0.49 MPa 80 NL / min

Machine Dimensions:

L: 1500 mm W: 1300 (2143) mm

(W: including MFU) H: 1409 mm

(H: excluding signal tower)

Weight: Main Body: Approx. 1.800 kg


JUKI RS-1R Pick and Place MachineJUKI RX-7R Pick and Place MachineJUKI RX-8 Pick and Place MachineJUKI RS-1R SMT Assembly LineJUKI RX-7R SMT Assembly LineJUKI RX-8 SMT Assembly Line.

We provide JUKI SMT assembly line solutions, including JUKI Assembly Line Equipments JUKI productsJUKI Pick and Place Machine MachineJUKI SMT Stencil PrinterJUKI Assembly LineJUKI SMT Reflow OvenJUKI SMT Inspection MachineJUKI SMT Spare PartsSMT EquipmentJUKI SMT Peripheral Equipment;  any kind SMT equipments you may need, please contact us for more information: wechat whatsapp:+8613691605420, Email: sales@flason-smt.com
1) This is the first time I use this kind of machine, is it easy to operate?
There is English manual or guide video that show you how to use machine.
If you still have any question, please contact us by e-mail/skype/phone/wechat online service.
2) If machine have any problem after I receive it, how can I do ?
Free parts send to you in machine warranty period.
If the part is less than 0.5KG, we pay the postage.
If it exceeds 0.5KG, you need to pay the postage.
3) MOQ ?
1 set machine, mixed order is also welcomed.
4) How can I buy this machine from you? ( Very easy and flexible !)
A. Consult us about this product on line or by e-mail.
B. Negotiate and confirm the final price , shipping , payment methods and other terms.
C. Send you the proforma invoice and confirm your order.
D. Make the payment according to the method put on proforma invoice.
E. We prepare for your order in terms of the proforma invoice after confirming your full payment And 100% quality check before shipping.
F.Send your order by air or by sea.
5)Why choose us ?
A. We have customer world wide, you can check our credit service with them !
B. Free Online installation, traning, programming and technical support !
C. One stop full Through Hole Assembly Line Equipments Solutions !
